Biomass Pellet Boiler - MCZ Compact 15 slim



Overall

Biomass Pellet Boiler

Hydro Nominal power 13.5 kW
Hearth thermal power 15 kW
Nominal performance 90%
Second class EN303-5 5
Dimensions (W x D x H) 989 x 279 x 1119 mm
Weight 200 kg
Smoke exhaust diameter 80 mm
Hopper capacity 40kg / 61.5L
Runtime with one load 13 h

Compact biomass pellet boiler ideal for confined spaces - under the staircase, storage room or small utility compartments.  High performance levels and extensive operating controls.


The hydraulic part can be fitted with 4 different kits depending on your system’s needs. Wide range of pellet loading and storage systems from 200kg to 1900kg. Check the temperature of the puffer tank or domestic hot water through the boiler’s panel ensures easy of use.


Load hopper with 60 litre/40 kg capacity (approximately)
Rear or top smoke exhaust available
Second class 5 EN 303-5/2012
Wide adjustment: from 4.5kW to 15kW
